Dimensions: 378.8 mm x 255.5 mm x 198.5 mm
Net Weight: around 3kg
Material: Aviation aluminum (specially hardened), stainless steel
Firing Mechanism: Automatic rebound manual brushless servo motor firing, with trigger overcurrent protection
Mounting Method: Quick-release four-point positioning, quick release installation
Observation Range: 1000 meters Linkage Method: Dual linkage for heading and pitch
Green Dot Laser: Maximum 500 meters
Night Vision Fill Light: Maximum 500m
Ranging Distance: Maximum 1000m
Optical Lens: 10x optical zoom, with crosshair, external manual calibration knob, APP cursor movement calibration, human and vehicle recognition
Power Supply: Onboard power supply
Operating Voltage: DC 24-60 volts
