Autel Evo II 640T V3 Series
Autel Evo II 640T V3 Series
Autel Evo II 640T V3 Series
Autel Evo II 640T V3 Series
Autel Evo II 640T V3 Series

Autel Evo II 640T V3 Series

Regular price $ 6,999.00 Sale price$ 5,799.00 Save $ 1,200.00
Shipping calculated at checkout.
Supplier: Autel

  • Low stock - 2 items left
  • Backordered, shipping soon

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Unrivaled Accuracy And Control

Centimeter-Level Positioning

The EVO II RTK Series V3 integrates an entirely new RTK module for 2022, which provides real-time centimeter-level positioning data in three minutes and supports Post-Processing Kinematic (PPK). The aircraft can record the original satellite observation data, camera exposure parameters and more. The positioning system supports RTK base station and NTRIP RTK network, which helps to achieve accurate and stable data acquisition in complex operation environments.
  • RTK Horizontal Positioning Accuracy: 1cm+1ppm
  • RTK Vertical Positioning Accuracy: 1.5cm+1ppm
  • No GCP Required

    EVO II RTK Series V3 connects to NTRIP network and does not need GCPs to provide centimeter grade accuracy.
  • 3rd Party Base Station Support

    EVO II RTK Series V3 supports all NTRIP compatible base stations.

Autel Explorer for Mapping

Multi-NTRIP Profile Saving

For repeatable data acquisition missions, you can record the drone's previous shooting positions. All the gimbals, camera, and aircraft movements will be replicated, thus producing a full record of the entire mission.

Photo Replication

The EVO II RTK Series V3 returns to where it left off in multi-battery missions without starting from the beginning.

Multi-Battery Missions

The Explorer App allows the user to create and save multiple NTRIP profiles for different locations without having to manually input account info every travel.

Advanced Feature Sets

  • Create Rectangular or Polygon Missions
  • Supports Double grid mapping for additional anglesustomizable
  • Have complete manual control over camera settings
  • Non stop turning on corners saves time and battery life
  • Customizable course headings to meet orientation requirements

Capture Every Detail

EVO II Pro RTK V3 has high dynamic range and powerful low light performance, enabling users to capture clear detail sets with minimal distortion and noise.
1-Inch Ultra-Sensitive Sensor
The EVO II Pro RTK V3 comes with a NEW updated 1-inch 6K CMOS image sensor with a maximum of 20 megapixels. Thanks to the ultra-sensitive algorithm, you can still shoot clean, detailed, low-noise data sets under twilight or night conditions.
F2.8~F11 Adjustable Aperture
Adapt to lighting changes by adjusting the lens aperture size, giving the pilot more shutter speed control.
  • Zoom in for the Details

    EVO II Pro RTK V3 has optimized its datasets to be easily adjusted with post processing software applications.
  • Optimized for Software Image Correction

    EVO II Pro RTK V3 has optimized its datasets to be easily adjusted with post processing software applications.

Dual Cameras, Accurate Temperature Measurement

The EVO II Dual 640T RTK V3 is equipped with a high-resolution thermal imaging camera and an all new Sony .8" 50 megapixel RYYB sensor.
High-Resolution Thermal Imaging Sensor
The sensor features an industry leading 640*512 high-definition thermal imaging resolution of 30hz.
Precise Temperature Measurement
The EVO II Dual 640T RTK V3 can accurately detect heat sources within a distance of 2-20 meters. By leveraging the compensation algorithm of infrared temperature measurement, the 640T RTK can regulate temperature deviations within 3 degrees Celsius.
  • New Image Processing Algorithm

    The V3 system uses a brand new image processing algorithm, making thermal imaging details sharper and more discernible than competition with the similar resolution and hardware.
  • 30hz Refresh Rate for Videogrammetry

    The EVO II RTK Dual V3 provides high refresh rates for accurate and detailed 3D thermal maps.
  • Zoom in for the Details

    Zoom in on critical areas with EVO II RTK V3 16x digital zoom that supports 4x lossless zoom.
  • Multiple Color Palettes

    White Hot | Cold and Hot | Rainbow | Enhanced Rainbow | Iron bow | Lava | Arctic | Searing | Gradation | Heat Detection

SkyLink 2.0 Video Transmission

EVO II RTK V3 Series V3 is upgraded with Autel's all new SkyLink 2.0 Video Transmission technology.


Fly farther with HD video transmission up to 15km.


Obtain critical details with QHD video within 1km.


Support tri-band communication and can automatically frequency hop for maximum anti-interference capability.
*900MHz is only applicable for FCC countries.

360° Obstacle Avoidance

Equipped with 19 groups of sensors including 12 visual sensors, the main camera, ultrasound, IMUs and other sensors enable building of three-dimensional maps and path planning in real time.
*Please refer to the manual for details on obstacle avoidance and its limitations, which may or may not work in limited lighting environments, under direct strong sunlight, or across thin tree branches or wires.

Portable and Easy to Use

  • Compact Design

    The EVO II RTK Series V3 folds up for ease of transport and deployment.
  • Trouble Free Daily Workflows

    The EVO II RTK V3 takes 45 seconds from launch to takeoff without fuss.

Safe and Sturdy

  • Wind Resistance

    EVO II's Smaller Cross Section and powerful motors allows greater stability and control in all windy conditions.
  • -
  • -
  • No Fly Zones

    EVO II RTK Series V3 does not have any no fly zones and will not prevent the pilot from taking off*.
  • 38 Minutes Flight Time

    Enjoy up to 38 minutes of flight time - 20%~30% more than the next leading competitor for more area coverage and longer missions.
  • -
  • -
  • No Forced Updates

    EVO II RTK Series V3 does not need to be on the latest hardware or app version in order to take off unlike other competitors.

Autel Smart Controller V3

Smart Controller V3's 7.9-inch, 2000nits high-brightness screen is clearly visible even under direct sunlight. SkyLink 2.0 Transmission technology guarantees long-distance operations from up to 15km away and enhances anti-interference abilities with triple band frequency hopping. The customized Android system allows for additional flexibility with 3rd party Apps and an IP43 rating ensures all weather performance.
  • 15km Transmission Range
  • Maximum 2000nits Brightness
  • 4.5 Operating Hours
  • IP43 Resistance

Broadcast with Live Deck 2

Broadcast live mission intel to other personnel in the operation for enhanced situational awareness and critical decision making. The EVO II Dual 640T V3 is compatible with Live Deck 2, which offers multiport streaming to monitors and Wifi support for multiple smart phones.
  • 1080P Video Stream
  • Three Auto-Switch Bands
  • 12KM Transmission Range
  • IP43 Resistance


  • Powerline Inspection
  • Photogrammetry
  • Law Enforcement
  • Firefighting
