Overview
800m+ Range. 2°–70° Zoom. Zero Visible Signature.
The IR3's VCSEL laser delivers 4W of 850nm infrared illumination with an electrically synchronized zoom that transitions from a 2° long-range beam to a 70° wide-area flood in under 2 seconds. At narrow angle, illuminate targets beyond 800 meters with a 28-meter light spot. At wide angle, flood a 112-meter diameter at 80+ meters. Full gimbal control with Pitch: -80° to +45° and Pan: ±90° keeps the beam locked on target across the full operational envelope.
Learn More +
See Further. Strike Precisely. Own the Night.
The CZI IR3 is a professional-grade infrared zoom dome light engineered for the DJI Matrice 30 and Matrice 30T. Delivering VCSEL laser illumination with an electrically synchronized zoom range of 2° to 70°, the IR3 gives thermal and low-light operators the ability to illuminate targets at distances exceeding 800 meters — with pinpoint accuracy and zero visible signature.
Variable Zoom Illumination — 2° to 70°
The IR3's electric synchronous zoom adjusts continuously from a tight 2° long-range beam to a wide 70° area flood in under 2 seconds. At narrow angle, the IR3 illuminates targets at over 800 meters with a 28-meter light spot. At wide angle, it floods an 112-meter diameter at 80+ meters — giving operators full control over illumination profile for any mission scenario.
VCSEL Laser Technology
Powered by a Surface-Emitting Laser (VCSEL) at 850nm ± 10nm, the IR3 delivers 4W of luminous power with exceptional efficiency and thermal stability. Class 3B laser safety certification (FDA, IEC) with a 15-meter minimum safety distance ensures compliant operation across professional and government deployments.
Full Gimbal Control
A precision gimbal with Pitch: -80° to +45° and Pan: ±90° range ensures the IR3 can track and illuminate targets across a wide operational envelope — keeping the beam on target regardless of aircraft orientation or subject movement.
Technical Specifications
- Compatible with DJI Matrice 30 / Matrice 30T
- Dimensions: 126.5 × 60 × 88.5 mm | Weight: 240 ± 5g
- Laser Type: VCSEL | Wavelength: 850 ± 10nm
- Luminous Power: 4 ± 0.5W
- Illumination Angle: 2.0° – 70° (electric synchronous zoom, ≤2s)
- Effective Distance: ≥300m (general) | ≥800m at 2° narrow angle
- Gimbal Range: Pitch -80° to +45° | Pan ±90°
- Laser Safety: Class 3B (FDA, IEC) | Safety Distance: 15m at minimum angle
When your thermal camera needs illumination that matches its reach, the IR3 delivers — with the zoom precision, range, and gimbal control to keep every target lit, every time.
