Everything you need to replace the Rear Frame on your DJI Agras T40.
| No. | QTY | Material Name 2 |
| 1 | 1 | Rear Frame Aluminum Tube |
| 2 | 5 | Outer Shell Buckle |
| 3 | 1 | Rear Upper Cover |
| 4 | 5 | T30-HC00800080-057030-5103-N |
| 5 | 7 | Rear Shell Small Buckle Base |
| 6 | 1 | Rear Lower Cover |
| 7 | 2 | Screw M40-HC01400140-070039-0003-Y |
| 8 | 4 | Damping Pad |
| 9 | 2 | Screw M30-HC100100-55-85 |
| 10 | 1 | Power Distribution Board Module |
| 11 | 2 | RTK Antenna Module |
| 12 | 4 | M30-HC01450080-100020-5103-Y |
| 13 | 1 | Backward Vision Sensor Radar Module (Outside of Mainland China) |
| 14 | 2 | Screw M30-HC060060-55-85 |
| 15 | 1 | Downward Vision Radar Bracket |
| 16 | 2 | Screw M30-HC100100-55-85 |
| 17 | 1 | Battery Buckle |
| 18 | 1 | Battery Buckle Sealing Ring |
| 19 | 2 | Screw M40-HC01400140-070039-0003-Y |
| 20 | 2 | Screw M30-HC100100-55-85 |
| 21 | 1 | Screw M30-HC100100-55-85 |
| 22 | 1 | Rear Frame Crossbeam |
| 23 | 2 | Screw M30-HC100100-55-85 |
| 24 | 2 | Buckle |
| 25 | 10 | Screw M40-HC01400140-070039-0003-Y |
| 26 | 1 | Real Shell Bracket |
