DJI Agras T-40 Front Frame Parts Package

DJI Agras T-40 Front Frame Parts Package

Regular price$ 1,799.00
/
Shipping calculated at checkout.
Supplier: DJI

  • In stock, ready to ship
  • Backordered, shipping soon

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

DJI Agras T-40 Front Frame Parts Package

This package contains everything you would need to replace faulty or damaged parts for the aircraft Front Frame on your DJI Agras T40 Aircraft.

This package includes:

No. QTY Material Name 2
1 4 M30-HC01450080-100020-5103-Y
2
1 Front Frame Aluminum Tube
3 1 Front Frame Insulation Sheet
4 1
5 2 Screw M30-HC100100-55-85
6 2 M25-HC060060-45-85
7 2 Dual Vision Sensors Sealing Ring
8 2 Damping Pad
9 2 M30-HC01450080-100020-5103-Y
10 1 FPV Bracket Decorative Piece (Right)
11 1 FPV Bracket Decorative Piece (Left)
12 1 Front Shell Bracket (Right)
13 2 T30-HC00800080-057030-5103-N
14 1 Propulsion Cable Clip
15 4 Screw M30-HC060060-55-85
16 2 Screw M30-HC060060-55-85
17 1 FPV Bracket
18 3 Screw M40-HC01400140-070039-0003-Y
19 1 Front Shell Bracket (Left)
20 1 FPV Module
21 2 Screw M30-HC060060-55-85
22 2 Screw M40-HC060060-55-85
23 1 Radar Crossbeam
24 1 Omnidirectional Radar Fixing Base_Heat Sink Part Sealing Ring
25 1 Screw M25-HC00780040-040020-5108-N
26 1 Omnidirectional Radar Fixing Base
27 3 Screw M40-HC01400140-070039-0003-Y
28 4
29 1 Omnidirectional Radar Fixing Base_Heat Sink Part Sealing Ring
30 1 Omnidirectional Radar Signal Cable
31 1 Radar Fixing Base Thermal Pad
32 4 Screw M30-HC060060-55-85
33 1 Omnidirectional Radar Module (Including Signal Cable)
34 1 Radar Hood Sealing Ring (Outer)
35 1 Forward Vision Sensor Module
36 1 Omnidirectional Radar Fixing Base Sealing Ring
37 1 Auxiliary Bottom Light Module (Including Signal Cable)
38 1 Front Frame Cable Bracket (Left)
39 4 Screw M40-HC01400140-070039-0003-Y
40 1 Auxiliary Bottom Light Signal Cable
41 1 Spraying Adaptive Cable
42 1 Front Frame Cable Bracket (Right)
43 1 Side Arm
44 1 M20-PC00400040-040010-5103-Y
45 1 Enhanced Supporting Piece
